Automatic 1kg 5kg Ice Cube Weighing Packing Machine
Machine Description：
This automatic weighing packaging machine with customized dosing system, the double screw weigher enable ice cube automatically feeding, weighing, filling and packing into roll film form bags.
To meet the diverse needs of customers, ice packaging machines are highly adaptable for wide weight range like 1-10kg with diverse bag types including pillow bags, gusseted bags, and tote bags, typically using low-cost PE film for packaging.
Machine Parameter：
| Parameter Sheet | ||||
| Model | ZEL-420W | ZEL-520W | ZEL-620W | ZEL-720W |
| Film width | 150-420mm | 180-520mm | 220-620mm | 260-720mm |
| Bag width | 65-200mm | 80-250mm | 100-300mm | 120-350mm |
| Bag length | 60-300mm | 80-400mm | 100-450mm | 120-500mm |
| Packing speed | 10-25 bag/min | 10-25 bag/min | 5-15 bag/min | 5-15 bag/min |
| Filling accuracy | +/-1%(per product) | +/-1%(per product) | +/-1%(per product) | +/-1%(per product) |
| Power supply | 220V 50/60Hz, 4KW | 220V 50/60Hz, 4.5KW | 220V 50/60Hz, 5KW | 220V 50/60Hz, 6KW |
| Air supply | 0.6-0.8MPA | 0.6-0.8MPA | 0.6-0.8MPA | 0.6-0.8MPA |
Machine Features：
Vertical packaging machines, also commonly known as vertical filling forming sealing (VFFS) machine, are highly efficient and automated packaging equipment. Starting from a roll of film, it automatically complete a series of processes including bag making, metering, filling, sealing, and cutting.
①High Efficiency and Automation
Vertical packaging machines achieve full automation from roll film to finished bags, with extremely high production speeds of 30-80 bags/min with continuous production time of 12 hours a day without interruption, meeting the needs of large-scale. The entire process requires only a small amount of manual labor, which reducing labor costs and labor intensity.
②Precise Metering and Secure Sealing
The equipment can be equipped with various high-precision metering system that depending on material characteristics (e.g., granules, powders, liquids), options such as combination scales, screw scales, measuring cups, or liquid pumps can be selected to achieve high-precision metering.
Horizontal and vertical sealing temperatures can be independently and precisely controlled by PID (temperature difference within ±1℃), adapting to various packaging materials such as PE, PP, and composite films, ensuring a smooth, secure, and leak-free seal.
③Diverse Packaging Forms and High Adaptability
Vertical packaging machines offer high flexibility, adapting to different product and packaging needs. By changing different forming devices, various bag types can be easily produced, including pillow bags, gusset bags, toe bags, ect.
Additional functions such as coding machines, nitrogen-filled preservation, easy-tear openings, and venting holes can be easily integrated to meet diverse market demands.
④Intelligent Control and Convenient Operation
Modern vertical packaging machines generally adopt advanced control systems, simplifying operation and maintenance. Equipped with a touchscreen, parameter settings, fault diagnosis, production counting, and other functions are clearly displayed, making operation simple and intuitive. Besides, an intelligent "no packaging without material" detection function to avoid empty bags and reduce waste.
Machine Details：
Machine whole set consists of feeding conveyor, double screw weigher, roll film bagging machine and output conveyor.
①Feeding conveyor with vibrating storage hopper to feed product up to the weighing system continuously.
②Customized double screw weigher via spiral propulsion technology can effectively handle damp and easily sticky ice blocks, while ensuring high-precision weighing down to the gram level.
③Roll film bagging machine automatically complete the entire process, including feeding, accurate weighing, bag making, filling, date printing, bag sealing, bag cutting, and counting.
④Output conveyor to convey finished products quickly to avoid piling up and connect to subsequent processes for production continuity.
Company profile:
Foshan ZHIEN Machinery Co, td.is a manufacturer specializing in automatic packaging solution,integrating R&D, design, production and marketingWe independent develope and produce premade bag packing machine, Vffs packing machine, pillow packing machine, filing machine and otherpacking equipment widely used in food, hardware, medical, daily use, agricultural, cosmetics and other industries.
Technical Advantages：
Professional Ice Cube Vertical Form Fill Seal Design
This large vertical roll film packing machine is specially customized for ice cube, ice block and edible ice packaging. It can automatically complete roll film forming, bag making, quantitative filling, sealing and cutting in one process, no need for pre-made bags, greatly saving packaging material cost.
Stable Bag Forming & Precise Length Control
Adopt high-precision film pulling servo system, stable bag forming, neat sealing and smooth bag shape. The bag length and weight can be adjusted freely via touch screen, suitable for multiple specifications of 1kg, 2kg, 5kg, 10kg ice cube packaging.
Low Temperature Resistant & Anti-Condensation Structure
Professional anti-condensation and anti-frost design for ice packaging working environment. The whole machine is optimized to avoid freezing, sticking and running instability under low temperature and high humidity workshop conditions, ensuring 24-hour continuous stable operation.
Intelligent PLC Control & Easy Operation
Equipped with international brand PLC and color touch screen, support multi-language switching. It stores multiple product formulas, realizes one-key switching between different ice specifications, simple operation and less dependence on workers.
High Packaging Efficiency & Wide Adaptability
Automatic continuous running speed is fast, suitable for large-scale ice factory mass production. It can match quantitative weighing scale to realize fully automatic weighing and packaging, greatly saving labor and improving production efficiency.
Reinforced Body & Anti-Corrosion Configuration
The main frame adopts thickened industrial steel structure, solid and shock-resistant. All material contact parts use 304 stainless steel, rust-proof, corrosion-resistant, easy to clean, fully adapt to cold storage and ice factory long-term use.
FAQ:
Q1: What kind of product is this machine suitable for?
A: This large vertical roll film packing machine is specially designed for ice cube, ice block, edible ice, drinking ice packaging, suitable for 1kg to 10kg per bag.
Q2: Does it need premade bags?
A: No need. It uses original roll film to automatically finish forming, bag making, filling and sealing, saving much bag cost compared with premade bag machine.
Q3: Can it work in low temperature and cold storage workshop?
A: Yes. The machine adopts professional anti-frost, anti-condensation and low-temperature resistant design, specially customized for ice factory high humidity and low temperature environment.
Q4: Can I adjust bag size and packaging weight?
A: Yes. Bag length, speed and weighing weight can be adjusted freely on the touch screen, and multiple specifications can be stored for one-key switching.
